富得巴国际贸易（上海）有限公司
| 产品名称 | 尺寸 | 颜色 | 分辨率 | 画素尺寸 | 显示区 [mm] | 外形尺寸 [mm] |
亮度 [cd/m2] |
偏光板 |
寿命[hrs] @50% Lighting rate |
驱动电压[V] | IC |
COG or COF |
接口 | SPEC Download | |||||||
| x | y | x | y | x | y | x | y | Thickness | Parrallel | SPI | I2C | ||||||||||
| ELW0901AA | 0.9" | White | 128 | 36 | 0.17 | 0.17 | 21.734 | 6.095 | 25.28 | 9.90 | 0.940 | 500 | without | 12000 | 13 | LD7032 | COG | 〇 |
|
||
| ELW1301BAP | 1.3" | White | 128 | 49 | 0.249 | 0.217 | 31.84 | 8.65 | 36.74 | 14.00 | 1.030 | 350 | without | 30000 | 12 | LD7032 | COG | 〇 | 〇 |
|
|
| ELW2106GAP | 2.05" | White | 256 | 64 | 0.198 | 0.194 | 50.66 | 12.39 | 60.60 | 17.50 | 1.340 | 250 | with | 10000 | 16.5 | SSD1362 | COG | 〇 |
|
||
| ELW3601AA | 3.55" | White | 256 | 64 | 0.342 | 0.333 | 87.528 | 21.288 | 94.70 | 30.80 | 1.540 | 140 | with | 10000 | 17 | SSD1322 | COG | 〇 |
|
||
